Sensaggio Technologies
Sensaggio Technologies is a innovative company that designs, manufactures and distributes ratiometric pressure sensors, biometric sensors, and complete technological solutions.
The company is able to start from the design phase of the components taking the correct approach from phase one considering the application and the specifications to pursue in agreement with the customer. In this way Sensaggio can manufacture and supply the most suitable solution.
Vision
Sensaggio, comes from a thirty years experience in the field of monitoring pressure sensors with different technologies and material combinations .
Sensaggio, in cooperation with selected business partners is able to offer pressure sensors based on piezoresistive technology using both ceramic and silicon materials. It also provides biometric sensors (heart beat, respiratory…).
OLEAVISION – protects your children in the car
Surveillance system in your car that, in case of detection of cardiac activity with the engine off and doors closed, sends an Alert on your mobile phone.
Sensaggio manufactures/distributes ceramic piezoresistive sensor based on an innovative concept.
The SA sensor over the past 2 years has been approved by 2 major car manufacturers and, exploiting the cost structure needed to be competitive with OEM car manufacturers, it was offered to the industrial sector
NEW RELEASE
Pressure Sensor output 4..20mA
main features
POWER SUPPLY: 8 ÷ 28 Vdc
POWER SUPPLY OVERVOLTAGE: +15% OF THE POWER SUPPLY
REVERSE VOLTAGE: 40 Vdc
OUTPUT CURRENT: 4 .. 20 mA
OUTPUT CORRENT LIMITATION: 3.2 .. 22.3 mA
OUTPUT LOAD: (Power supply – 8V)/0.025A
OUTPUT RESPONSE TIME: 5 ms Max
FREQUENCY LIMIT RESPONSE: 2kHz
INSULATE RESISTANCE >10MOhm at 500Vdc
OPERATING TEMPERATURE: -40°C + 135°C
PROTECTION LEVEL: IP 67 WITH MECHANICAL PROTECTION
ACCURACY: Max +/- 1% F.S. at 25°C
CYCLE LIFE: 10 MILIONS CYCLES
DROP 1.5 m
OPERATING PRESSURE: 0.5 – 8 bar ABS
1 -17 bar ABS
1 -19.2 bar ABS
1 -31 bar ABS
1 -45.8 bar ABS
ASSEMBLY TORQUE: 12 ÷ 16 Nm
BURST PRESSURE: 172 bar
WEIGH: 0.05 Kg
COMPATIBLE WITH REFRIGERANTS: R134A, R404A, R407C, R507A, R417A, R245fa, R290, R600, R600a, R1270, R717, R1234ze, R1234yf R1234zd, R744 – oil, gasoline, water
PACKARD CONNECTION: PPA
BODY: Brass – Aluminum- Stainless Steel
We Are Growing Rapidly
The leading Companies in the Automotive, Bio-Medical, Safety, Security, Industrial, and Aerospace sectors choose Sensaggio with excellent results.
Applications
Automotive
Oil Pressure
Fuel Vapor
Smart Suspension
Fuel Level
Fuel Pressure
Brake Pressure
Transmission Pressure
Industrial
Hydraulics
Compression
Agriculture
Refrigeration
Tank Level
P-to-I Converters
Pressure Indicator
Heating, Ventilation, & Air Conditioning (HVAC)
Medical
Disposable Blood Pressure Sensor
Catheter Tip Pressure Sensor
Kidney Dialysis Equipment
Angioplasty Inflation Pump
Infusion Pumps
Heart beat monitoring
Safety monitoring
Breath monitoring
Disease monitoring
Consumer
Consumer
Digital Tire Pressure Gage
Altimeters/Barometers
Scuba Diving Gauges
Aviation
Altitude
Tire Pressure
Hydraulic Pressure
Brake Pressure
Defense
Hydraulic Pressure
Tire Pressure
Brake Pressure
Our Projects
The experience and the technical know how which were common among the personnel of the company have enabled the launch of an ambitious project that led to the creation of a new ceramic pressure transducer completely designed, industrialized and manufactured in Italy.
We can support our customers in many applications
HVAC-T
transportation: bus, truck, ships, trains
Oil system pressure
Fuel system pressure
Ad blue
Portable HVAC
HVAC-R (industrial automation)
HVAC-R portable monitoring system
.
Process monitoring
Automation process control
.
.
Car connected
Life safety
Collisions Detection
Fire safety
.
.
HVAC after market
.
.
.
Heart beat monitoring
Biometric systems
tracks respiratory function
Movement detection
.
.
.
Detection life presence
Intrusion Detection Surveillance
.
.
.
Hydraulic systems
.
.
Services
-
Customer Care
We can offer to the customer the best service in terms of product, quality, timing, packaging, tracking.. From the order to the logistics Sensaggio handles everything in an efficient and professional way in terms of documentation, transportation, custom clearance, orders management, quality claims etc…
-
Consultancy - Testing
Sensaggio takes care its products from the design to testing: Testing means electrical, EMC, vibration, temperature and life cycles, power cycles, Xrays, hermeticity, simulation, functional, contamination, material assessment…. Sensaggio has several partners that can take care of the assembly and of the testing needed to validate a product (TS and UL certifications etc…)
-
Recycling
Through our partner we can make sure that any precious or semiprecious metal during your fabrication is not wasted.
We have the possibility to first analyze and quantify the amount of precious metal coming from your scraps. At that point you are sure to get back either the precious metal or the equivalent amount of money (your choice).
More and more customers are looking at this way to maximize their margins. We can recycle, through a state of the art technology, materials, finished products, slurry…practically any type of waste containing precious metals.
